PANTHER 6×6 12,500L

CHASSIS:

• Chassis type: RBI PANTHER Chassis 39.735 6×6
• Wheelbase: 4,800 mm
• Engine output: 540 kW/735 HP

TECHNICAL DATA:

• Vehicle dimensions L x W x H: 11,750 x 3,000 x 3,650 mm
• Permissible total weight: 39,000 kg

DRIVER’S CAB:

• Crew:1+3

EXTINGUISHING SYSTEM:

• Water tank: 12,500 L
• Foam tank: 1,500 L
• Powder tank: 250 kg
• Pump system: N80
  • Maximum output 9,000 L/min
• Foam proportioning system: FIXMIX 2.0 E
  • fully automated around the pump foam system
• Dry powder unit: PLA 250 kg
• Proportioning rate: 1%, 3% and 6%
• Extinguishing output NP: 8.000 L/min at 10 bar
• Extinguishing output HP: 250 L/min at 40 bar
• Rapid intervention hose reel: LP and HP hose reel
• Roof turret: RM80C
  • Maximum output 9,500 L/min
• Front turret: RM15C
  • Maximum output 2,000 L/min

ADDITIONAL EQUIPMENT:

• Auxiliary heating in crew cab
• LED scene lighting
• Seats with integrated SCBA holder optional
• Reversing camera
• LED equipment compartment lighting

• ESC (Electronic Stability Control)
• Alarm start button on left exterior side of cab
• Searchlight, LED, electrically adjustable
• Thermal imaging camera, on cab roof
• Rosenbauer Comfort 100 Ladder lowering device
