Volvo 4,000L Pumper

Chassis:

• Volvo FMX 440 4×4
• Engine Output: 440 hp D13
• Transmission: I-Shift automated 12 speed
• Wheelbase: 4.900 mm

Cab:

• Crew: 1+5
• Volvo original crew cab
• Original Volvo steps
• 4 Rosenbauer COMFORT breathing apparatus

Superstructure:

• Rosenbauer aluminium superstructure consisting of a self-supporting, screwed sheet metal and profile construction

Equipment compartments:

• Full height body with roller shutter and hinged steps
• COMFORT revolving shelves for the optimum removal and safe storage of equipment.

Control system:

• Electric system with manual switches
• Pressure governor

Extinguishing systems:

• Type: NH35 combined normal/high-pressure pump
• Output: from 3,500L/min at 10 bar, 400 L/min at 40 bar
• Water tank volume: 4,000L
• Foam tank volume: 400L
• Automatic around-the-pump foam proportioning system: FIXMIX 3+6% external foam suction line

▪ Pressure outlets:

› Four manual pressure outlets in the rear side compartments left an right

▪ Quick attack unit:

› Rear-mounted, high pressure hose reel (25 mm hose, 60 m)

▪ Water monitor

› Rosenbauer RM24M on the roof

Maximum output 3,000 L/min

▪ Lighting mast:

› Rear mounted pneumatic lighting mast with LED lamps

▪ Electrical systems:

› LED flashing blue lights integrated in the rear superstructure
› Surrounding area lighting with LED spread beam lights mounted on both side of the roof gallery and on the rear
› Electric cable winch WARN 54kN

Dimensions and weight

L x W x H Max 9.150 x 2.500 x 3.800 mm
Permitted gross weight 18.000 kg
